Wind
Screen Fix

Dolphin Windscreen Fix is highly recommended for directly glazing of automobile glass replacement (AGR). It provides an excellent adhesion on materials like glass, ceramic, painted or naked metal (Aluminum, steel, etc.) and cut PU and EPDM rubber beading etc.

TDS  |   MSDS

Description

Key Features

  • Excellent Adhesion in-between windscreen glass, metal, EPDM rubber beading.
  • No Shrinkage
  • Non-corrosive
  • Bonding and Sealing of sunproof system

Typical Uses

  • Automobile windscreen glass fixing
  • Interior & Exterior Application
  • Excellent bonding of metal to metal
  • Bonding with metal to Aluminum, wood to wood
  • Good bonding in metal, aluminum with Glass
  • Excellent adhesive usages for BTR application (Bus, Track, Rail)

Surface preparation

The substrate areas that will be in contact with adhesive must be clean, dry, and free of all loose materials, dust,
dirt, rust, oil, and other contaminants.

Tooling and finishing

End use application wise tooling and finishing not required.

Storage

9 months in the original cartridges and sausages, 6 months in the drum.Hermetically store the products between 5 and 25℃.

Instructions

Substrate preparation:
The substrates to be assembled must be dry, clean, free of oil and other contaminants that could adversely affect
the bonding performance, use a cleaner or primer if necessary.

Handling precautions

Not classified as hazardous. Read the material safety data sheet before use.

Cleanup and removal

Uncured adhesive can be removed by wiping MEK or Acetone, but cured adhesive can be removed by mechanically.

KEEP OUT OF REACH OF CHILDREN | KEEP CONTAINER TIGHTLY CLOSED  | FOR INDUSTRIAL & POFESSIONAL USE

Packaging

Sr. NoVolumePackaging Type
1.310 mlcartridges
2.400 mlsausages
3.600 mlsausages



Technical Properties

Sr. No PropertiesSpecifications
1.ColorBlack
2.AppearanceThixotropic paste /High viscosity
3.Density at 20℃Ca 1.35 g/ml
4.Application temperature5 to 35 ℃
5.Curing speedCa.3.5mm/24hours
6.ShoreAHardnessCa.55 (ISO868 – 3 seconds)
7.Tensile strength (DIN 53504)5.5±1.0 Mpa (After 7days)
8.Shearing resistance (FORD DELTA)3.0 ±0.5 Mpa (After 7days)
9.Tearing resistance (DIN53515)>11N/mm
10.Elongation at break (DIN 53504)>400%
11.Resistance to solvents and hydrocarbonsModerate
12.Acid and base resistanceGood
13.Water and salt spray resistanceExcellent
